Projection Technology | RGB liquid crystal shutter projection system (3LCD) | |
Cool Down Period | Instant Off | |
Contrast Ratio | 16,000:1 | |
Brightness | White Light Output (Normal/Eco) | 3,600 lm |
Colour Light Output | 3,600 lm | |
Projectors Facets | Contrast Ratio, Projectors Facets | 16,000:1 |
Brightness Range Lumens, Projectors Facets | 2000 | |
Features, Projectors Facets | Wifi,Quick Corner | |
Resolution, Projectors Facets | XGA | |
Laser / Lamp, Projectors Facets | Lamp | |
Specifications of Main Parts | LCD | Native Resolution: XGA (1024 x 768) Size: 0.55” (C2fine) |
Lightsource | Type: 210W UHE Life (Normal / Eco): 6,000 / 12,000 hours |
|
Aspect Ratio | 04.03 | |
Projection Lens | F-Number: 1.49 – 1.72 Type: Optical Zoom (Manual) / Focus (Manual) Focal Length: 16.90 – 20.28 mm Zoom Ratio: 1 – 1.2 Throw Ratio1.48 – 1.77 (Wide to Tele) |
|
Screen Size (Projected Distance) | Standard Size | Tele: 30” to 300” [1.07 to 10.95 m] Wide: 30” to 300” [0.89 to 9.12 m] |
Connectivity | USB Interface | USB Type A: 1 (For Wireless LAN, Firmware Update, Copy OSD Settings) USB Type B: 1 (For Firmware Update, Copy OSD Settings) |
Network | Wireless: Optional (ELPAP11) | |
Analog Input | Composite: 1 RCA D-Sub 15pin: 1 |
|
Digital Input | HDMI: 1 (MHL not supported) | |
Audio Input | 2 RCA: 1 | |
Dimension Excluding Feet (W x H x D) | 302 x 77 x 234 mm | |
Weight | Approx. 2.5 kg | |
Power Supply Voltage | 100 - 240 V AC ±10%, 50/60 Hz |
