| Projection Technology | RGB liquid crystal shutter projection system (3LCD) | |
| Projectors Facets | Resolution, Projectors Facets | XGA |
| Contrast Ratio | Projectors Facets 16,000:1 | |
| Brightness Range Lumens, Projectors Facets | 2000 | |
| atures, Projectors Facets | Wifi,Quick Corner | |
| Laser / Lamp, Projectors Facets | Lamp | |
| Brightness | White Light Output (Normal/Eco) | 3,800 lm |
| Colour Light Output | 3,800 lm | |
| Connectivity | USB Interface | USB Type A: 1 (For Wireless LAN, Firmware Update, Copy OSD Settings) USB Type B: 1 (For Firmware Update, Copy OSD Settings) |
| Network | Wireless: Optional (ELPAP11) |
|
| Analog Input | Composite: 1 RCA D-Sub 15pin: 1 |
|
| Specifications of Main Parts | LCD | Native Resolution: XGA (1024 x 768) Size: 0.55” (C2fine) |
| Lightsource | Type: 210W UHE Life (Normal / Eco): 6,000 / 12,000 hours |
|
| Aspect Ratio | 04.03 | |
| Projection Lens | Type: Optical Zoom (Manual) / Focus (Manual) F-Number: 1.49 – 1.72 Focal Length: 16.90 – 20.28 mm Zoom Ratio: 1 – 1.2 Throw Ratio: 1.48 – 1.77 (Wide to Tele) |
|
| Dimension Excluding Feet (W x H x D) | 302 x 77 x 234 mm | |
| Weight | Approx. 2.5 kg | |
